2019 Mespack H-320-4

4 x Used Mespack H-320/4 Quadruplex  horizontal-, form-, fill-, and seal machine. From the year 2019.

The machine is equipped  with the following options, run 4- side sealed pouches in quadruplex, with two compartments and 2 different powders

•Monobloc frame of carbon steel

•All product touching parts in AISI 316

•Reel edge aligner

•Infeed system for dividing film

•Photocell

•Servo driven unwinding

•Bottom seal

•4 x Notch device

•Servo driven film pulling

•First opening system

•Quadruplex servo motor Auger filler

•First stretching system

•Second opening system

•Quadruplex servo motor Auger filler

•Second stretching system

•Motor driven height adjustment of auger filler

•Vibratory product feeders to auger fillers

•Dust extraction mouth

•Frontload transfer arm

•Omron PLC

Size range: Min.  40 x 50 mm

                   Max. 80 x 240 mm

Filling volume: Max  100 cc

Capacity:  300-380 pouches/min

4 machines available: 2 left-right/2right left
